| Place of Origin | China |
| Brand Name | TBC |
| Certification | CE-EMC, CE-LVD, RoHS, ETL, FCC |
| Model Number | D481 |
Quick Details:
1, Pixel Pitch: 4.81mm, SMD1921 LEDs.
2, RGB Full colors: 281trillions.
3, Wide viewing angle: 160°/ 160°.
4, Standard cabinet size: 500×500x80mm, 500x1000x80mm.
5, Outdoor IP65 waterproof and dustproof.
Features:
1, Thin and light weight, save labor cost, operating cost and transportation cost.
2, Fast assembling and easy installation with handle and fast lock design.
3, Aluminium cabinet, good thermal design, excellent heat dissipation even no fan installation.
4, High refresh rate 3840Hz, no ghost, exquisite and clear picture and video performance.
| Parameter | Unit | Value | ||
| Brightness | nits | 4200 | ||
| Color temperature | deg.k | 3200 ~ 9300 | ||
| Viewing angle - Horizontal | deg. | 160(+80/-80) | ||
| Viewing angle - Vertical | deg. | 160(+80/-80) | ||
| Cabinet weight | kg | 14 | ||
| Cabinet width | mm | 500 | ||
| Cabinet height | mm | 1000 | ||
| Cabinet depth | mm | 80 | ||
| Cabinet area | sq. m. | 0.50 | ||
| Cabinet material | Aluminum | |||
| Aspect ratio | 1:2 | |||
| Ingress protection (Front/Rear) | IP | IP65/IP54 | ||
| Operating temperature range | deg. C | - 20 to 50 | ||
| Operating humidity range | HR | 10％ to 90％ | ||
| Pixel type and configuration | R/G/B | SMD 3in1 | ||
| Pixel pitch | mm | 4.808 | ||
| Pixel matrix per cabinet | 104x208 | |||
| Pixels per cabinet | 21321 | |||
| Lines per meter | 207 | |||
| Pixels per sq. meter | 43258 | |||
| LEDs per sq. meter | 43258 | |||
| Recommended minimum viewing distance | m | 5 | ||
| Colours | 281trillion | |||
| Gray scale | Levels | 65536 levels per colour | ||
| Brightness control | Levels | 100 | ||
| Digital processing | bit | 16 | ||
| Frame rate | Hertz | 60 | ||
| Display refresh rate | Hertz | 1920 | ||
| Input voltage | VAC | 110/240 | ||
| Input power frequency | Hertz | 50/60 | ||
| Input power (max/avg) | Watts per sq.m | 750/260 | ||
| MTBF | Hours | ≥10000 | ||
| Lifetime (50%Brightness) | Hours | ≥100000 | ||
| Module brightness uniformity | ＜5％ | |||
| Blind spot rate | ＜0.0001 | |||
| Earth leakage current | mA | ＜2 | ||
| Red wavelength | nm | 623 | ||
| Green wavelength | nm | 525 | ||
| Blue wavelength | nm | 470 | ||
| Panel input format (with video processor) | VGA,DVI,SDI,YPbPr(HDTV),Composite,S-Video,TV | |||
| Data interconnection | CAT6 cable/Fiber | |||
| Operating system | Windows(XP/Vista/7/8/10) | |||
| Control distance | Up to 180 meters by CAT6 cable, single fiber up to 15 kilometers. | |||
