Netherlands 250sqm LED Perimeter Stadium Quick Service Durable Quality High Refresh rate 3840Hz
  • Netherlands 250sqm LED Perimeter Stadium Quick Service Durable Quality High Refresh rate 3840Hz
  • Netherlands 250sqm LED Perimeter Stadium Quick Service Durable Quality High Refresh rate 3840Hz
  • Netherlands 250sqm LED Perimeter Stadium Quick Service Durable Quality High Refresh rate 3840Hz
  • Netherlands 250sqm LED Perimeter Stadium Quick Service Durable Quality High Refresh rate 3840Hz

Netherlands 250sqm LED Perimeter Stadium Quick Service Durable Quality High Refresh rate 3840Hz

Place of Origin China
Brand Name TBC
Certification CE-EMC, CE-LVD, RoHS, ETL, FCC
Model Number P12
Product Details
Location:
Netherlands
Product:
Outdoor Led Perimeter
Pixel Pitch:
12mm
Cabinet:
Aluminum
Dimension:
1280x960mm
Refresh Rate:
3840Hz
High Light:

customer success stories

,

customer case study

Product Description

Netherlands 250sqm LED Perimeter Stadium Quick Service Durable Quality High Refresh rate 3840Hz


Application:


Outdoor P10mm Football Stadium Led Banner Screen Display Outdoor IP65 Aluminum Cabinet are the most durable design of led stadium perimeter for 250sqm LED perimeter for De Kuip stadium, Rotterdam


Features and Advantages:


Content Control / Data Interfacing(UEFA Standard)

  • Optional: Individual control of brightness, gamma, colours of every single pixel/ module/cabinet.
  • Default images (auto-switch feature) installed and enabled (set to static shared-rotation) in case of total connection loss with server.
  • System viewed and operated as one single screen by control software.
  • Control signal connection via two redundant feeding points. Fibre optic data cabling from dedicated controller locations to the two return side corners.
  • Data ring loop configured; if one connection fails an automatic switch activates data source from the opposite section.

Mechanical(UEFA Standard)

  • Quick-service modules. Module / cabinet change time <1 min, without affecting running system – i.e. hot-swappable.
  • Mechanism for access gates at several locations (optional), with no signal interruption.
  • Mechanical connectors to align the system, and minimise gaps between cabinets.
  • Black non-glare finishing on face-plate, and black/dark neutral colours on cabinet.
  • Weather-protection to IP-65 (front) and IP-54 (back) standard.

  • Rubber louvers front and top to protect cabinets from impact and players from injuries
  • Transport casing designed for efficient storage and shipping (for transportable systems).


Electrical(UEFA Standard)

  • European-voltage system (220-240V, 50Hz).
  • Single-PSU-failure tolerant concept.
  • Heavy, high flex rubber cabling for cold enviroment outdoor use.
  • EMC protection to highest EU standards and regulations.





Parameters



Brightnessnits6000
Color temperaturedeg.k3200 ~ 9300
Viewing angle - Horizontaldeg.160(+80/-80)
Viewing angle - Verticaldeg.160(+80/-80)
Cabinet weightkg50
Cabinet widthmm960
Cabinet heightmm960
Cabinet depthmm150
Cabinet areasq. m.0.92
Cabinet material Cold Steel
Aspect ratio 4:3
Ingress protection (Front/Rear)IPIP65/IP54
Operating temperature rangedeg. C- 20 to 50
Operating humidity rangeHR10% to 90%
Pixel type and configurationR/G/BSMD 3in1
Pixel pitchmm10
Pixel matrix per cabinet 96x96
Pixels per cabinet 9216
Lines per meter 100
Pixels per sq. meter 10000
LEDs per sq. meter 10000
Recommended minimum viewing distancem10
Colours 281trillion
Gray scaleLevels65536 levels per colour
Brightness controlLevels100
Digital processingbit16
Frame rateHertz60
Display refresh rateHertz1920
Input voltageVAC110/240
Input power frequencyHertz50/60
Input power (max/avg)Watts per sq.m960/330
MTBFHours≥10000
Lifetime (50%Brightness)Hours≥100000
Module brightness uniformity <5%
Blind spot rate <0.0001
Earth leakage currentmA<2
Red wavelengthnm623
Green wavelengthnm525
Blue wavelengthnm470
Panel input format (with video processor) VGA,DVI,SDI,YPbPr(HDTV),Composite,S-Video,TV
Data interconnection CAT6 cable/Fiber
Operating system Windows(XP/Vista/7/8/10)
Control distance Up to 180 meters by CAT6 cable, single fiber up to 15 kilometers.
