Indoor P1.5625 GOB LED Poster Display with 600nit Brightness and 33mm Ultra-thin Panel for Front Window Advertising
  • Indoor P1.5625 GOB LED Poster Display with 600nit Brightness and 33mm Ultra-thin Panel for Front Window Advertising
  • Indoor P1.5625 GOB LED Poster Display with 600nit Brightness and 33mm Ultra-thin Panel for Front Window Advertising
  • Indoor P1.5625 GOB LED Poster Display with 600nit Brightness and 33mm Ultra-thin Panel for Front Window Advertising
  • Indoor P1.5625 GOB LED Poster Display with 600nit Brightness and 33mm Ultra-thin Panel for Front Window Advertising

Indoor P1.5625 GOB LED Poster Display with 600nit Brightness and 33mm Ultra-thin Panel for Front Window Advertising

Place of Origin China
Brand Name TBC LED
Certification FCC, CE, ROHS, etc.
Model Number GOB P1.56
Product Details
Pixel Pitch:
P1.5625(GOB)
Cabinet Size:
1006X2181X33; 756X2181X33
Brightness:
600cd/sqm
Thickness:
33mm
IP Rating:
IP31
Module Size:
250x250mm
Material:
Die-casting Aluminum
Warranty:
2 Years
Maintenance:
Front Access Service
Highlight:

P1.56 GOB LED Poster Display

,

600nit Indoor Digital Signage Panel

,

Ultra-thin 33mm Front Access LED Screen

Product Description
Indoor P1.56 GOB LED Poster Display 600nit Ultra-thin 33mm Panel for Front Window Advertising
Product Overview

The Indoor P1.56 GOB LED Poster combines fine pixel pitch with 600nit brightness in an ultra-thin 33mm profile. Designed for front window advertising, retail displays, and commercial lobbies, it delivers crisp, vibrant visuals that capture attention instantly.

Technical Specifications
Pixel Pitch P1.5625 (GOB)
LED Type SMD1212 / SMD1010 (GOB)
Physical Density 409,600 dots/m²
Module Size 250 * 250 mm
Cabinet Size 1006 * 2181 * 33 mm / 756 * 2181 * 33 mm
Screen Resolution 640 * 1280 / 480 * 1280 dots
Brightness 600 nit
Color Temperature 5000-12000 K (Optional)
Viewing Angle 160° / 160° (V/H)
Brightness / Color Uniformity ≥ 97%
Contrast Ratio 10000 : 1
Frame Frequency 50 / 60 Hz
Scan Mode 1/40 Scan
Gray Scale 14 / 16 bit (Optional)
Refresh Rate 3840 Hz
Max Power Consumption 400 W/m²
Average Power Consumption 100-200 W/m²
Power Voltage Range AC 90-264 V, 47-63 Hz
Working Temp. / Humidity -20~60 °C / 10%-85%
Storage Temp. / Humidity -20~60 °C / 10%-85%
Maintenance Mode Front Access Service
Cabinet Material Die-Cast Aluminum
Protection Level IP31
Certifications CCC, CE, RoHS, FCC, CB, TUV, IEC, BIS
Warranty 2 Years
Indoor P1.56 GOB LED Poster Display technical diagram
Cabinet Dimensions

Available in two sizes to match any space:

Large: 1006 * 2181 * 33 mm – 640 * 1280 dot resolution, 409,600 dots/m² density, ideal for storefront windows and mall corridors.

Compact: 756 * 2181 * 33 mm – 480 * 1280 dot resolution, same fine-pitch clarity in a narrower footprint, perfect for entrances and narrow walkways.

Both share the same 33 mm ultra-thin profile and die-cast aluminum frame, ensuring a sleek, lightweight build that blends into any interior.

Key Advantages
1. Pin-Sharp Visuals, Photo-Ready

P1.5625 fine pitch with 3840 Hz refresh delivers flicker-free images. Take photos or videos of the screen – no scan lines, just clear content every time.

2. GOB Protection Built In

Glue-on-Board coating seals each LED against moisture, dust, and accidental bumps. Tougher than standard SMD, safer for busy public spaces.

3. Slim 33mm, Fits Glass Windows

Mount directly behind window glass – the 33 mm depth sits nearly flush. Bright 600nit output cuts through reflection, drawing eyes from outside.

4. Front Service, No Hassle

All modules accessible from the front. Swap a module in minutes without pulling the unit off the wall – keep your advertising running.

5. Set Up in Minutes

Built-in media player with USB plug-and-play, Wi-Fi control, and multi-screen cascading. Unbox, plug in, and go – no PC required.

Indoor P1.56 GOB LED Poster Display installation example Indoor P1.56 GOB LED Poster Display close-up view
Why Choose TBC LED
15+ Years LED Manufacturing

Engineered and produced in-house with full certifications – CCC, CE, RoHS, FCC, CB, TUV, IEC, BIS. Every panel meets global quality standards.

Full-Cycle Support

Dedicated team guides you from product selection through installation and after-sales – one contact, zero run-around.

Fast, Secure Shipping

1,000 sqm monthly output, 15-day lead time. Packed in plywood cases or flight cases – your order arrives intact, on schedule.
