COB Indoor LED Video Wall: High-Definition Displays with Advanced Durability
  • COB Indoor LED Video Wall: High-Definition Displays with Advanced Durability
  • COB Indoor LED Video Wall: High-Definition Displays with Advanced Durability
  • COB Indoor LED Video Wall: High-Definition Displays with Advanced Durability
  • COB Indoor LED Video Wall: High-Definition Displays with Advanced Durability
COB Indoor LED Video Wall: High-Definition Displays with Advanced Durability

COB Indoor LED Video Wall: High-Definition Displays with Advanced Durability

Place of Origin China
Brand Name TBCLED
Certification 3C, CE, CB, ETL, FCC, ROHS, CQC
Model Number HD LED Display
Product Details
Pixel Pitch:
0.78mm,0.93mm,1.25mm,1.56mm,1.87mm
Panel Size:
600*675*39.5mm
Panel Weight:
7.9kg
Viewing Angle:
160°
Maintenance Way:
Front Service
IP Level Of PCB Serface:
IP54（Washable By Clean Water）
Brightness:
600nits
Refresh Rate:
3840Hz
Flash Correction Storage:
Applicable
Product Description

COB Indoor LED Video Wall: High-Definition Displays with Advanced Durability



COB Indoor LED Video Wall Precision


The COB Indoor LED Video Wall merges Chip-on-Board innovation with small pitch engineering to deliver unmatched visual performance. By embedding LED chips into epoxy-sealed PCB grooves, it eliminates dust accumulation in pixel gaps, maintaining clarity in dusty environments like factories or construction lobbies. The sub-2mm pitch ensures sharpness for both large video walls and compact info kiosks.



Specifications of COB Indoor LED Video Wall


Pixel Pitch 0.78mm 0. 93mm 1. 25mm 1. 56mm 1.87mm
Module 150*168. 75mm
Resolution (dot) 192*216 160*180 120*135 96*108 80*90
Surface Treatment Matt COB
Panel Size 600*675*39.5mm / 600*337. 5*39. 5mm
Panel Weight 7. 9kg ( 600*675mm) / 4kg ( 600*337. 5mm)
Panel Resolution (dot)

768*864/

768*432

640*720/

640*360

480*540/

480*270

384*432/

384*216

320*360/

320*180
Pixel Density(dot/㎡) 1,638,400 1,137,777 640,000 409,600 284,444
Circuit Design Common cathode circuit
Flash Correction Storage Applicable

Brightness of White

Balance

 Standard 600nits
Refresh Rate 1920~3840Hz
Contrast Ratio 10000: 1 (Condition without lighting)
Color Temperature 9300K(Standard)
Viewing Angle 160°
Input Voltage AC 100~240V 50/60Hz


Max. Power Consumption

(White Balance 600nit)

170W/Panel (600*675mm);

85W/Panel (600*337mm)

150W/Panel (600*675mm);

75W/Panel (600*337mm)

140W/Panel (600*675mm);

70W/Panel (600*337mm)

140W/Panel (600*675mm);

70W/Panel (600*337mm)

130W/Panel (600*675mm);

65W/Panel (600*337mm)
Maintenance Way Front Service
IP level of PCB serface IP54(Washable by clean water)
Operating Temperature -10°C-+40°C/10%RH-90%RH
Stroage Temperature -20°C-+60°C/10%RH-90%RII
Certificate 3C, CE, CB, ETL, FCC, ROHS, CQC




COB Indoor LED Video Wall Standout Benefits

  1. Long-Lasting Performance
    Copper thermal pathways reduce junction temperatures by 25°C, extending LED lifespan to 100,000 hours—3x longer than traditional SMD displays.

COB Indoor LED Video Wall: High-Definition Displays with Advanced Durability 0

2.COB Indoor LED Video Wall Flexible Installation

Customizable PCB thickness (1.2mm–3.0mm) adapts to curved surfaces (radii as tight as 50cm), enabling creative designs like cylindrical kiosks or wave-shaped backdrops.

COB Indoor LED Video Wall: High-Definition Displays with Advanced Durability 1



3.COB Indoor LED Video Wall Simplified Maintenance
Hot-swappable modules allow repairs without powering down, minimizing downtime. The smooth, non-porous surface resists fingerprints and is easy to clean with standard disinfectants—critical for healthcare settings.


COB Indoor LED Video Wall  Cost-Efficient Operation

Low heat output reduces HVAC loads by 20%, while modular design cuts replacement costs—only damaged panels need swapping, not entire sections.

COB Indoor LED Video Wall Technical Highlights

  • Anti-Glare Technology: Matte surface reduces reflections by 70%, ideal for sunlit lobbies.
  • Signal Redundancy: Dual input ports (HDMI/DP) prevent blackouts in critical applications like traffic control centers.
  • Smart Calibration: Built-in sensors auto-adjust brightness based on ambient light, saving energy by 25%.

COB Indoor LED Video Wall Applications

  • Smart Stadiums: Close-up viewing screens for VIP boxes with 4K live feed support.
  • Museum Exhibits: Interactive historical timelines with touch-sensitive overlays.
  • Factory Control Rooms: Real-time production monitoring with high-contrast data visualization.

COB Indoor LED Video Wall: High-Definition Displays with Advanced Durability 2

COB Indoor LED Video Wall: High-Definition Displays with Advanced Durability 3

COB Indoor LED Video Wall: High-Definition Displays with Advanced Durability 4
